Underground Mobile Trash Compactor
Swing technology is an ideal space saving, clean and representative waste collection solution. There is only a litter bin located on the ground that is visible to the user, other components are hidden under the ground. Swing waste management system underground compactor is lifted and lowered back to be hidden under the ground mechanically with a help of a multi lift system of the emptying truck.
Product Advantage
New Design
The underground mobile trash compactor adopts an internationally advanced, fully enclosed ground layout with an attractive appearance, making it convenient and efficient for users to dump waste.
2. Multiple Options
The underground mobile trash compactor offers a variety of feed options, including a hopper, a tipping bucket, and a dump port for bulky waste, suitable for both manual and vehicle loading.
3. Excellent Performance
The underground mobile trash compactor system utilizes a four-cylinder lift for smooth lifting. Its frame is constructed of high-strength, thick steel plates, ensuring excellent waterproofing. Capital investment is minimal, requiring no additional installation or commissioning.
4. Standardization
The underground mobile trash compactor is compatible with most standard hook-type garbage trucks worldwide.
5. Versatile
The underground mobile trash compactor system is equipped with automatic fire extinguishing, deodorization, ventilation, and automatic cleaning features. The spray spray effectively deodorizes and disinfects, with adjustable spraying time and frequency. A high-pressure water jet can also be used to rinse the tank surface and the ground.
Technical Parameters
Model | ZYM-6 | ZYM-9 | ZYM-12 | ZYM-15 | ZYM-18 |
Volume (m ³） | 6 | 9 | 12 | 15 | 18 |
Tank Dimensions （L*W*H）(mm) | 3980*2210*2200 | 4770*2210*2200 | 5080*2260*2250 | 5560*2300*2300 | 6150*2480*2410 |
Power(kw) | 11 | 11 | 11 | 15 | 15 |
| Foundation measurement design Additional controls e.g. emergency stops Custom filling hopper Drainage system 2-phase discharge door opening mechanism Top hinged discharge door Ozone generator / cooler device (odor control) Bin lift (integrated / stationary) Lid opening system (hydraulic / electronic) Auto start system | ||||
Optional | Garbage Bins: 240L*4 / 660L*2 (Garbage bins can be used for sorting or storing garbage temporarily when the tank is transferred.) Pit Flushing: high-pressure large volume water flow flushing, 6 nozzles for one-time automatic flushing; 500L sewage collection tank; automatic sewage discharge by sewage pump. (This technology is protected by independent intellectual property rights.) Remote Monitoring | ||||
Product Function
Product Effects
Lifting mode
Landing mode
Product Uses
Urban communities: can be installed near urban residential areas and apartment buildings to collect various types of garbage generated by residents in their daily lives, such as kitchen waste, waste paper, plastic bottles, etc. Compress and treat these garbage in a timely manner to reduce the space occupied by garbage, reduce the frequency of garbage removal, keep the community environment clean and hygienic, and avoid garbage accumulation to produce odor and breed bacteria.
Commercial centers: In crowded commercial areas such as shopping malls, shopping centers, and commercial streets, a large amount of commercial garbage, including packaging materials, food residues, etc., is generated every day. Underground garbage compactors can quickly process these garbage, prevent garbage from accumulating in commercial areas, and maintain a good business environment and image.
Public institutions: suitable for public institutions such as schools, hospitals, and government agencies. A large amount of waste paper and meal waste generated by students in schools, medical waste in hospitals (under the treatment process that complies with relevant regulations), and office waste in government agencies can all be effectively treated by underground garbage compactors to improve the environmental sanitation level of public institutions.
Transportation hubs: Airports, railway stations, bus stations and other transportation hubs have large passenger flow and generate a lot of garbage. Underground garbage compactors can promptly compress various types of garbage discarded by passengers, keep transportation hubs clean and hygienic, and provide passengers with a good travel environment.
CUSTOM DROP
According to customer needs, we can choose a variety of feeding port modes such as garbage sorting and dumping port, bucket tipping device, large garbage opening device, etc.,
CUSTOM FLOOR MATERIAL
The surface material can be arranged according to your surroundings, hiding the location of the compression station, ensuring smooth roads and achieving beautiful result.
Our Advantages
The system is equipped with automatic fire fighting, deodorization, ventilation and automatic clean facilities. Spray effecitvely reduces odor and disinfects, whose time and frenquency can be set up. High pressure water gun can rinse the surface of the tank and floor.
FAQ
1.Question: Are you a factory or trading company?Answer: We are a factory with our own export authority, which have many employees with strong R&D ability
2.Question: Some customers have some new item or part but can find in the web-site,can you product it?
Answer: we need images or artworks, samples you provide. lf you have 3D artwork will help us to checkfaster, Evaluating and considering product in mass production is workable according our equipment, Wewill give you a detail quotation.
3.Question: How do u ensure your product quality?Answer: We have a system quality control procedure, from incoming material, part, semi-product andfinal product 100% check. Material, semi-product, product function
4. Question: How do u do with the after-sales service?Answer: For our design/production/package problems, Ruining will take full responsibility. For shipmentproblems, we have full reports to help claims with shipping company.
We are a professional manufacturer of sanitation machinery, providing customers with ex-factory prices and on-demand customization services. You can contact us via WhatsApp or email.
