Hopper Garbage Compactor is a device that receives garbage through a hopper (feed port) and compacts the garbage using a mechanical or hydraulic system. It is widely used in sanitation, industry, commerce and other scenarios.
Product Advantage
Adaptable to various feeding methods: Hopper Garbage Compactor has a large volume and a wide inner width. Whether it is a flatbed truck, electric vehicle, small dump truck, tractor, or trash can, bagged garbage, etc., it can be easily matched with feeding, and can adapt to different garbage collection scenarios and garbage sources.
Automatic feeding operation: Hopper Garbage Compactor is equipped with a lifting mechanism, which can automatically pour the garbage in the hopper into the compression chamber to achieve automatic feeding, save manpower, improve feeding efficiency, and reduce the labor intensity of operators.
Good sealing: Hopper Garbage Compactor has good sealing performance during the garbage feeding, compression and storage process, which can effectively prevent the odor of garbage, garbage spillage and sewage overflow, reduce pollution to the surrounding environment, and improve the working environment and surrounding air quality.
Technical Parameters
Performance Parameters | |
Compression | Horizontal |
Waste bin volume (m³) | 6m³， 9m³,12m³ ，,15m³ ,18m³，Custom sizes |
Hook centre height (mm) | 1570 |
Density of compressed rubbish block(kg/m³) | 750kg/m³ |
Compression cycle time (s) | 45s |
Max. lifting force of tipping bucket | 1t,1.5t,2t,2.5t,2.5t |
Tipping bucket volume (m³) | 1.5m³,2.5m³,3.2m³,4.1m³,4.1m³ |
Rated power of motor(kW) | 5KW,5.5KW,7.5KW |
Machine weight (kg) | 4800kg,5500kg,6080kg,6580kg, |
Power supply | Local working voltage |
Operation mode | automatic + manual |
Size | 6m³: 4180 * 2440 * 2600 (mm); Tipping bucket falling height 2410mm. 9m³: 5080 * 2440 * 2600 (mm); Tipping bucket falling height 2410mm. 12m³ :4180 * 5280 * 2600 (mm); Tipping bucket falling height 2410mm. |
Product Video
Hopper garbage compactors have become the core equipment for waste reduction in various scenarios due to their high efficiency, low cost, high compatibility and strong environmental protection. Their advantages are particularly reflected in their adaptability to bulk and mixed garbage, as well as their low maintenance and easy operation, which are suitable for users who have high requirements for equipment durability and cost performance. With the improvement of environmental protection standards, hopper compressors will be further popularized in the construction of "zero-waste cities", helping to achieve efficient and sustainable garbage treatment.
|
|
