Screw Waste Compactor is a device that compresses garbage through the rotation and extrusion of a spiral propeller. It has the characteristics of compact structure, flexible operation and strong adaptability. It is widely used in scenarios such as garbage volume reduction, transfer and pretreatment.
Product Advantage
The Screw Waste Compactor is highly practical. It can not only process ordinary household garbage, but also crush and compress large wooden garbage such as small sofas, wooden boards, and wooden boxes, effectively solving the problem of equipment damage caused by complex garbage composition in some areas. The equipment can achieve continuous feeding and continuous compression without waiting for unloading time, which can significantly improve work efficiency and meet the needs of large-scale garbage disposal.
Product Parameters
Performance Parameters | |
Compression | Horizontal |
Waste bin volume (m³) | 6m³， 9m³,12m³ ,15m³ ,18m³，Custom sizes |
Hook centre height (mm) | 1570 |
Density of compressed rubbish block(kg/m³) | 750kg/m³ |
Compression cycle time (s) | 45s |
Max. lifting force of tipping bucket | 1t,1.5t,2t,2.5t,2.5t |
Tipping bucket volume (m³) | 1.5m³,2.5m³,3.2m³,4.1m³,4.1m³ |
Rated power of motor(kW) | 5KW,5.5KW, 7.5KW |
Machine weight (kg) | 4800kg,5500kg,6080kg,6580kg, |
Power supply | Local working voltage |
Operation mode | Automatic + manual |
Size | 6m³: 4180 * 2440 * 2600 (mm); Tipping bucket falling height 2410mm. 9m³: 5080 * 2440 * 2600 (mm); Tipping bucket falling height 2410mm. 12m³ :4180 * 5280 * 2600 (mm); Tipping bucket falling height 2410mm. |
Product Uses
The Screw Waste Compactor reduces the volume of garbage through the rotation and squeezing of the spiral shaft. It has the characteristics of compact structure, low energy consumption and easy operation. It is widely used in small and medium-scale garbage disposal scenarios and the pretreatment of specific types of garbage.
Product Operate Guide
Waste is fed into a hopper and then pushed by the rotating screw into a compaction chamber.
The screw compresses the waste, significantly reducing its volume.
The compacted waste is then discharged into a container or transport vehicle.
Many screw compactors can also dewater wet materials by separating liquids from solids.
Features
The Screw Waste Compactor are extremely durable as all hydraulic and electrical parts are completely isolated from the press chamber. Their factory-tested water proof design effectively eliminates effluent seepage and minimizes odors.
Waste management system as standard, enabling integration to Fleet Management system. The system provides insights on asset data and tools for streamlined fleet management.
