The Spiral Garbage Compactor is an environmentally friendly equipment that uses the principle of spiral propulsion to continuously or intermittently compress, reduce volume and dehydrate various types of garbage. Compared with traditional hydraulic compaction machines, it is widely used in municipal sanitation, sewage treatment, industrial solid waste treatment and other fields due to its features such as continuous operation, low noise, low energy consumption and low risk of blockage.
Advantages of Spiral Garbage CompactorContinuous and stable operation: Unlike hydraulic intermittent cycles, it can handle continuous feed and improve work efficiency.
Low energy consumption and low noise: The power is only 60-70% of that of hydraulic machines with the same processing capacity. It has low noise and is suitable for use in residential areas and indoors.
Anti-clogging design: Suitable for processing long fibers and large pieces of materials, it is less likely to get stuck and reduces downtime for cleaning.
Fully enclosed structure: Effectively prevents odor diffusion and leakage of filtrate, complies with environmental protection requirements, and improves the operating environment.
Modular design: Each component is independent and detachable. Replacing wear parts is simple and convenient, and the maintenance cost is low.
Adaptable to various materials: Can handle municipal waste, kitchen waste, sludge, industrial waste residue, plastics, waste paper, etc., with strong versatility.
Low operating cost: Apart from routine lubrication, there are no additional costs such as hydraulic oil replacement. The lifespan of wear parts is long.
Core Component Of Spiral Garbage CompactorSpiral body: Carries garbage and generates squeezing pressure.
Box body: Made of Q235/Q345 carbon steel, it is sealed to contain garbage and prevent leakage.
Compaction and dehydration module: Separates solid and liquid, controls compaction density.
Drive system: Provides stable power and regulates rotational speed and torque.
Feed hopper: Receives garbage and guides it into the working area.
Permeate liquid collection system: Collects the dehydrated material and prevents secondary pollution.
Control system: Controls operation, monitors parameters, and ensures safety.
Supporting sealing components: Supports operation and seals to prevent leakage.
Product ParametersPerformance Parameters | |
Compression | Horizontal |
Waste bin volume (m³) | 6m³， 9m³,12m³ ,15m³ ,18m³，Custom sizes |
Hook centre height (mm) | 1570 |
Density of compressed rubbish block(kg/m³) | 750kg/m³ |
Compression cycle time (s) | 45s |
Max. lifting force of tipping bucket | 1t,1.5t,2t,2.5t,2.5t |
Tipping bucket volume (m³) | 1.5m³,2.5m³,3.2m³,4.1m³,4.1m³ |
Rated power of motor(kW) | 5KW,5.5KW, 7.5KW |
Machine weight (kg) | 4800kg,5500kg,6080kg,6580kg, |
Power supply | Local working voltage |
Operation mode | Automatic + manual |
Size | 6m³: 4180 * 2440 * 2600 (mm); Tipping bucket falling height 2410mm. 9m³: 5080 * 2440 * 2600 (mm); Tipping bucket falling height 2410mm. 12m³ :4180 * 5280 * 2600 (mm); Tipping bucket falling height 2410mm. |
Working PrincipleFeed: Garbage falls into the internal cavity of the equipment through the feed hopper.
Transport and propulsion: The screw rotates, pushing the garbage forward and performing initial compression.
Compaction and dehydration: The garbage enters the wedge-shaped filter area, the space gradually decreases, and the screw continuously applies pressure, extracting moisture and significantly reducing the volume of the garbage.
Solid-liquid separation: The leachate passes through the filter and is discharged through the outlet, and is collected uniformly by the collection system.
Discharge: The compressed and reduced-volume garbage is pushed by the screw to the discharge port and automatically discharged.
Application ScopeMunicipal sanitation: Community garbage stations, mobile transfer stations, garbage classification centers, for handling mixed garbage, kitchen waste, waste paper, plastic, etc.
Wastewater treatment: Urban waste treatment plants, industrial waste treatment stations, for compacting grit, sludge, and debris from sedimentation tanks.
Food processing: Processing organic waste such as vegetable residues, fruit peels, and meat processing waste to achieve volume reduction and dehydration.
Industrial solid waste: Plastic recycling plants, slaughterhouses, waste paper recycling plants.
Agricultural sector: Processing straw, vegetable greenhouse waste, to prepare for subsequent resource utilization.
The Spiral Garbage Compactor is an efficient, environmentally friendly and low-maintenance garbage disposal device. Its core advantage lies in the use of the spiral propulsion principle to achieve continuous compression and dehydration, avoiding many drawbacks of traditional hydraulic equipment. By reasonably selecting the model and configuring appropriate parameters, it can meet the waste reduction processing needs in different scenarios, helping to improve the efficiency of garbage disposal, reduce transportation and disposal costs, and minimize the risk of secondary pollution.
We are an established equipment manufacturer equipped with state-of-the-art production facilities, including CNC laser cutting machines, CNC bending machines and machining centers. These ensure our products’ superior quality and exquisite finish.
We accommodate custom design requirements based on drawings, backed by a robust technical team and skilled welding professionals. We look forward to cooperating with you.
