Vertical Garbage Compacting Station is an environmentally friendly device that integrates mechanical, electrical, and hydraulic systems and utilizes vertical compression technology. Its core principle is to use gravity to discharge waste from above into a vertical container, where it is then compressed and reduced in volume by a compactor. It primarily serves urban communities, factories, mines, government agencies, and universities, enabling the collection, compression, and closed transfer of domestic and solid waste, facilitating efficient waste treatment and low-carbon transportation.
Product Advantage
1. High compaction density
The compression mode of Vertical Garbage Compacting Station is vertical compression. Compared with horizontal compression, the compression density of vertical compression is greater (the compression density of vertical compression is 0.9t/m3, while the compression density of horizontal compression is 0.7-0.9t/m3. The garbage is compressed to form blocks, which reduces the transportation times and transportation costs.
2. Closed operation in the whole process of waste treatment
The garbage box of the Vertical Garbage Compacting Station is an integral structure, with a storage bin in the front, a compression bin in the middle and a push block mechanism in the rear; The transfer carriage is a closed structure, so the garbage is in a closed state in the process of compression, temporary storage, pushing block and transfer, so as to avoid garbage falling off and leakage and reduce the emission of odor.
Technical Parameters
Compression Type | Vertical compression |
Bin Capacity(m³) | 6m³-20m³ (Professional customization) |
Height of Hook (mm) | Customize height |
Density of Garbage Compactor(kg/m³) | 750kg/m³ |
Cycle Time of Compression(s) | 45s |
Operating Mode | Automatic; manual |
Color | Customizable colors |
Material | Corrosion-resistant manganese steel |
Power | Hydraulic/Chain (Customize) |
Lifting Mode | Hydraulic four-post lifting |
Product Uses
Vertical Trash Compacting Station are mainly used for centralized compression of domestic waste in densely populated areas such as urban communities, commercial areas, schools, and hospitals.
Run Process
Garbage Collection: Garbage is transported to the equipment and enters the collection device.
Garbage Compression: The equipment compresses the collected garbage to reduce its volume (for easier storage and transportation).
First Block of Garbage Storage: The compressed first block of garbage is moved to the "storage area" to free up space for subsequent collection.
Second Block of Garbage Collection and Compression: New garbage is collected and the "compression" process is repeated to form a second block of compressed garbage.
Multiple Block of Garbage Storage: After multiple cycles of "collection-compression-mobile storage," multiple blocks of compressed garbage accumulate in the storage area.
Transfer Truck Docking: The garbage transfer truck arrives and docks with the compression equipment, preparing for loading.
Garbage Loading: The stored compressed garbage is pushed onto the transfer truck, completing the loading process.
Return to Collection: After the transfer truck departs, the equipment returns to its initial "garbage collection" state and enters the next operating cycle.
The entire process achieves efficient garbage processing (reducing volume and facilitating long-distance transportation) through "compression and volume reduction" + "centralized transfer", which is a typical operating model of urban garbage transfer stations.
Product Style
|
|
Product Features
The main body of the vertical garbage compactor runs vertically, and the ground area occupied is usually 8~20 square meters (only 1/2~1/3 of the horizontal compressor).
Underground design: The compression box can be embedded in the ground, leaving only the operating surface on the ground, further saving space and beautifying the environment (such as old residential areas, scenic spots and other areas with high landscape requirements).
Applicable scenarios: city centers, areas with tight land resources or narrow streets. The compression process is completed in a closed box or pit, equipped with a sealed door and leak-proof design to effectively curb the spread of odor, mosquito and fly breeding and sewage leakage.
Supporting deodorization and sewage treatment: Some equipment integrates negative pressure ventilation, biological deodorization devices and leachate collection systems, which meet environmental protection standards and reduce the impact on the surrounding environment.
Our Advantages
(1) More than 20 years professional manufacturer experience.
(2) CCC ISO9001 agreement
(3) Be designed according to your requirements
(4) Small order can be accepted
(5) We accept 100% inspection, welcome to our factory at any time
(6) 12 month quality guarantee term
FAQ
1. What is your Warranty?
We provide 1 Year Warranty.
2. May l buy samples from you?
Yes! You are welcome to place sample order to test our superior quality and service.
3.What's the leading time? (How long do you need to prepare my goods?)
Standard models are in stock, customized models are 30-40 days
4.How will you deliver my goods to me?
Available by sea and rail.
5.What is the quality of your products?
We provide unrivaled Quality - Very rigorous testing process for Incoming Quality Control, input Process Quality Control, and Final Quality Control for every piece.We follow QC test procedure, and do 100% FQC to ensure your satisfaction.
We are a professional manufacturer of sanitation machinery, providing customers with ex-factory prices and on-demand customization services. You can contact us via WhatsApp or email.
