The large-capacity Split Garbage Compactor specially designed for industrial parks is the core equipment for addressing the large-scale processing needs of industrial solid waste, mixed garbage, packaging waste, etc. It adopts a modular design with the main unit fixed and the box separated, which solves the problems of large garbage production, frequent transportation, and high environmental protection requirements in industrial parks. It realizes an efficient operation mode of continuous compression and non-equivalent transportation, enabling industrial parks to achieve the development goals of land conservation utilization, energy conservation and carbon reduction, and compliant emissions.
Product Type
Product Advantage
Large processing capacity, suitable for industrial scale
High daily processing capacity. Each unit can independently handle waste for small and medium-sized parks, and multiple units can be linked for large parks to cope with the explosive growth of waste during peak production periods;
The compression efficiency is improved rapidly. Compared with traditional integrated equipment, the turnover frequency of transfer vehicles is reduced, significantly lowering transportation costs.
Compliant with environmental regulations and meeting strict standards
Odor emissions are in compliance with standards, and the treatment of leachate is also in compliance with standards, fully meeting the environmental acceptance requirements of the industrial park;
The fully enclosed operation design ensures no dust flying, no sewage leakage, and low operating noise, creating a green and clean park environment.
High cost-effectiveness, reducing the total life cycle cost
The initial investment is moderate, allowing for flexible configuration of the number of cabinets as needed, avoiding excessive investment;
The service life of the mainframe exceeds 10 years, the replacement cost of vulnerable parts of the cabinet is low, the hydraulic system is modularized, fault detection is quick, and downtime losses are reduced;
The power consumption is low, compared to traditional equipment, it saves more than 30% of energy, and the long-term operating cost is significantly reduced.
Flexible adaptation, suitable for complex scenarios
Compatible with various types of waste such as household garbage, industrial solid waste, kitchen waste, and packaging waste, and adaptable to different scenarios including manufacturing parks, chemical parks, and logistics parks;
It occupies a small area and does not require large-scale infrastructure renovations. It can be flexibly deployed in corners of the park or upgraded in existing transfer stations.
Core Structure and Working PrincipleModular Structure Design
Compact Main Unit (Fixed Installation):
Hydraulic System: Pump Station, providing extremely high compression force to ensure the density of garbage compaction;
Compression Chamber: Made of thickened anti-corrosion steel plate, resistant to wear and corrosion, suitable for complex components of industrial garbage;
Electrical Control System: PLC fully automatic control, supporting three modes of automatic / semi-automatic / manual switching, simple operation, reducing manual intervention.
Storage Box, detachable and replaceable:
Volume selectable from 10 to 20 m³, supports multi-box configuration for one machine, total processing volume can be high, meeting the daily massive garbage storage needs of industrial parks;
The rear door is equipped with hydraulic locking, double-layer rubber sealing strip design, airtight and leak-proof;
Standardized lifting interface, compatible with boom trucks for rapid transfer, the box can be independently repaired and replaced without affecting the continuous operation of the main unit.
Efficient Operation Process
Garbage Loading: Placed through the loading port, it supports various loading methods such as garbage collection vehicles and conveyor belts, suitable for the diversity of industrial garbage;
Compression: The garbage is first compressed in the pre-pressure chamber, then repeatedly squeezed by the horizontal hydraulic push head, efficiently expelling air and filtrate, with a high compression ratio;
Container Transfer: When the container is full, it is quickly separated from the main unit, and directly lifted by the transfer vehicle to the treatment site. Empty containers are immediately replenished to achieve 24-hour continuous operation;
Environmental Treatment: Integrated with an independent collection tank for filtrate, negative pressure ventilation, and spray deodorization system, the entire process is sealed and pollution-free.
Product ParametersPerformance Parameters | |
Equipment Model | ZYG-15/17/20 |
Compacted Density (t/㎡) | ≥0.75 |
Motor Power (kW) | 11/15/22 |
Hydraulic System Set Pressure (MPa) | 16~20 |
Case Volume (㎡) | 15/17/20 |
Power Supply (V) | 380v, 3-phase, 50HZ |
Application Scenario Large manufacturing parks: centralized treatment of production waste and packaging garbage from industries such as automotive, electronics, and machinery;
Chemical parks: compression and transfer of non-hazardous solid waste;
Logistics and warehousing parks: efficient processing of high-frequency garbage such as courier packaging and pallet waste;
Industrial park waste transfer stations: regional coordinated treatment, suitable for the operational requirements of industrial parks and waste transfer stations.
We are a professional manufacturer of sanitation machinery, providing customers with ex-factory prices and on-demand customization services. You can contact us via WhatsApp or email.
