High Pressure Sealed Hopper Garbage Compactor

 Product Overview

 Core Structure & Working Principle of High Pressure Sealed Hopper Garbage Compactor

Sealed Feeding Hopper

The front integrated hopper is the waste feeding port of the High Pressure Sealed Hopper Garbage Compactor. Optional flip-type sealed hopper cover. When feeding waste, the hopper opens; during compaction and transportation, the cover closes tightly to block odor overflow, prevent flies and wind-blown garbage scattering.

High Pressure Hydraulic Compression System

Equipped with heavy-duty hydraulic cylinder to provide powerful compaction force. The compression ratio reaches 3:1 ~ 6:1, waste volume can be reduced by up to 80%. Less transportation trips, lower fuel and labor cost. PLC automatic control supports continuous cyclic compaction operation.

Full Sealed Tank Body & Leachate Collection Structure

As the core advantage of the High Pressure Sealed Hopper Garbage Compactor, the whole container adopts multi-channel sealing strips for tailgate, hopper cover and joint surfaces. Built-in sewage collection tank gathers waste leachate. No sewage dripping during transportation, effectively avoid secondary pollution.

Standard Hook Lift Connection Base

The bottom and front frame are reinforced with high-strength alloy steel, reserved standard hook lifting lugs, perfectly compatible with all mainstream hook lift trucks. No extra modification required for matching hook lift truck.

 Operation Mode — Transported Entirely by Hook Lift Truck

The biggest highlight of the High Pressure Sealed Hopper Garbage Compactor is the flexible operation mode supported by hook lift truck transfer:

One hook lift truck serves multiple sealed hopper garbage compactors

Place several High Pressure Sealed Hopper Garbage Compactors at different waste collection points. While the hook lift truck transports the full compactor to landfill / waste treatment plant, empty compactors keep receiving waste on site. Eliminate waiting time for garbage accumulation, maximize hook lift truck utilization rate.

Fast loading & unloading by hook lift truck

The hook lift truck’s hydraulic hook arm automatically hooks, lifts and pulls the whole sealed hopper garbage compactor onto the truck platform. The whole loading process only takes 3–8 minutes. After arriving at disposal site, the hook lift truck can directly tilt and unload all compressed waste.

No waste transfer inside the truck

The garbage stays inside the sealed compactor container all the time. Avoid secondary handling waste, reduce odor diffusion and sewage leakage risks during transit.

Flexible site shifting

When business scope changes, the hook lift truck can easily relocate the High Pressure Sealed Hopper Garbage Compactor to new communities, factories or commercial zones, no foundation demolition required.

 Main Technical Features

 Key Advantages of High Pressure Sealed Hopper Garbage Compactor

• High Pressure Compaction, High Loading CapacityStrong hydraulic compression system improves single-transport waste volume, cut transport frequency and overall operation expenditure.
• All-Round Sealed Design, Environmental FriendlyName-oriented Sealed Hopper structure: sealed feeding hopper + sealed rear door + internal leachate collection tank. Stop odor escape, sewage dripping, rubbish flying. Perfect for urban downtown, residential areas and food markets with strict environmental requirements.
• Full Mobile Design, Hook Lift Truck CompatibleStandard hook lift interface fits universal hook lift truck (hook arm garbage truck). No dedicated fixed transport vehicle needed. Easy to rent or configure existing hook lift fleets.
• Small Occupied AreaThe High Pressure Sealed Hopper Garbage Compactor needs no large civil foundation. Only flat hard ground is required for placement. Suitable for sites with limited space such as underground parking lots, community corners and small transfer stations.
• Low Maintenance & Long Service LifeMain body adopts thickened Q345 wear-resistant manganese steel. Hydraulic components use well-known brand parts; sealed strips are replaceable. Simple daily maintenance, stable long-time continuous work.
• Multiple Customization OptionsWe support custom compactor capacity: 6m³, 8m³,10m³,12m³,16m³,20m³,24m³,26m³. Optional wireless remote control, automatic bin lifter, anti-corrosion coating, stainless steel inner tank for wet waste. Voltage can be customized according to regional standards.

 Application Scenarios

• Municipal waste collection & community waste transfer stations

• Shopping malls, commercial plazas, hotels, hospitals

• Food markets, catering industrial parks, food processing factories

• Tourist attractions, parks, large exhibition venues

• Manufacturing factories, logistics warehouses

• Coastal cities needing anti-leakage waste transport

• Projects requiring hook lift truck cyclic waste transportation

 Technical Reference Parameters

• Product Name: High Pressure Sealed Hopper Garbage Compactor

• Available Volume: 6 ~ 26 Cubic Meters

• Compression Ratio: 3:1 ~ 6:1

• Driving Mode: Electro-hydraulic drive

• Control System: PLC automatic control + manual emergency operation

• Main Material: Q355 High strength wear-resistant steel

• Transfer Vehicle: Standard hook lift truck / hook arm garbage truck

• Sealing Structure: Multi-layer rubber sealing, integrated leachate tank

• Feeding Method: Ground hopper feeding, optional wheelie bin lifting device

 FAQ

Can the High Pressure Sealed Hopper Garbage Compactor be transported by hook lift truck?

Yes. Our High Pressure Sealed Hopper Garbage Compactor is manufactured with standardized hook lifting connection structure. The whole compactor container can be directly loaded, transported and unloaded by hook lift truck. One hook lift truck can cycle among multiple sealed hopper garbage compactors to improve waste collection efficiency.

Is this sealed hopper garbage compactor leak-proof for wet waste and kitchen waste?

The High Pressure Sealed Hopper Garbage Compactor adopts fully sealed hopper and rear door, equipped with independent leachate collection box. It effectively prevents sewage leakage during compaction and hook lift truck transportation, suitable for high-moisture wet waste.

What size hook lift truck matches this garbage compactor?

Different capacity compactors correspond to different tonnage hook lift trucks. 6–12m³ compactors match 12–18 ton hook lift truck; 16–26m³ models fit 20–30 ton heavy-duty hook lift truck. We can provide matching parameter suggestions according to your existing hook lift truck.

What is the difference between mobile sealed hopper garbage compactor and fixed waste compactor?

Fixed compactors cannot move. The High Pressure Sealed Hopper Garbage Compactor is a mobile compaction container. After full loading, the entire unit is carried away by hook lift truck. It can be moved freely without fixed foundation, more flexible for scattered waste collection points.

Can I customize the color, size and extra functions of the high pressure sealed hopper garbage compactor?

Full customization is supported. We adjust container dimensions, hopper structure, add bin lifting mechanism, remote control system, anti-corrosion treatment according to customer requirements.

Contact Us for Custom Quotation

If you are looking for reliable High Pressure Sealed Hopper Garbage Compactor matched with hook lift truck, welcome to send us your demand: required volume, waste type, local hook lift truck parameters, special customization needs. We provide factory direct price, technical drawing, installation guidance and global after-sales support.
