Bucket Garbage Compressor is a device used to compress garbage and improve the efficiency of garbage collection and processing. Bucket Garbage Compressor is mainly used in commercial, industrial and municipal waste treatment scenarios.
Product Advantage
High compression efficiency: Significantly reduces the volume of loose waste, minimizing space usage and increasing the equipment's single-load capacity.
Low transfer costs: Increased loading capacity reduces the number of waste transport trips, lowering fuel consumption, vehicle wear and tear, and labor costs, making it particularly suitable for centralized waste collection scenarios.
More convenient operation: Equipped with an automatic bin-tipping mechanism, it can directly connect to standard waste bins, eliminating the need for manual handling and emptying, reducing labor intensity and improving operational efficiency.
More environmentally friendly: Compacterized waste has better sealing, reducing leachate leakage, odor diffusion, and insect breeding, thus lowering the risk of secondary pollution.
Wide applicability: Suitable for various locations such as residential communities, schools, shopping malls, and industrial parks, compatible with different types of household waste, offering strong versatility.
Core Functions
Tipping and Unloading: Equipped with a hydraulically driven tipping mechanism, it can automatically tip over 240L/660L standard garbage bins for unloading;
Garbage Compression: Compacts loose garbage through a horizontal compression mechanism;
Mobile Transfer: Can be used with hooklift trucks for transfer, making it a mobile garbage compression container;
Auxiliary Functions: Some models include deodorization, spraying, and automatic cleaning facilities.
Product Operation Process
Activate the tipping function. Control the tipping mechanism via the control panel to tilt the bin, emptying the garbage from the bin into the equipment's feeding hopper. After emptying, reset the tipping mechanism.
After the garbage is poured in, start the compaction program. The compaction pusher slowly advances, compressing the loose garbage to the set density.
For continuous feeding, repeat the "tipping feeding → compaction" steps until the feeding hopper reaches its rated loading capacity.
After loading is complete, drive the equipment to the designated unloading point and activate the unloading mechanism. The compacted garbage is pushed out via the pusher or the rear door.
Technical Parameters
Performance Parameters | |
Compression | Horizontal |
Waste bin volume (m³) | 6m³,9m³,12m³ ,15m³ ,18m³,Custom sizes |
Hook centre height (mm) | 1570 |
Density of compressed rubbish block(kg/m³) | 750kg/m³ |
Compression cycle time (s) | 45s |
Max. lifting force of tipping bucket | 1t,1.5t,2t,2.5t,2.5t |
Tipping bucket volume (m³) | 1.5m³,2.5m³,3.2m³,4.1m³,4.1m³ |
Rated power of motor(kW) | 5KW,5.5KW,7.5KW |
Machine weight (kg) | 4800kg,5500kg,6080kg,6580kg, |
Power supply | Local working voltage |
Operation mode | Automatic + manual |
Size | 6m³: 4180 * 2440 * 2600 (mm); Tipping bucket falling height 2410mm. 9m³: 5080 * 2440 * 2600 (mm); Tipping bucket falling height 2410mm. 12m³ :4180 * 5280 * 2600 (mm); Tipping bucket falling height 2410mm. |
Product Details
The RNKJ series of Bucket Garbage Compressor to empty their waste bins safely and efficiently. Our systems can be customized to meet your needs. RNKJ Bucket Garbage Compressor can lift and empty nearly any type of wheelie bin or waste container, placing it into a compactor or roll-off bin.
These units are available in a wide variety, from stationary units with integrated compactors, mobile wheelie bin lifts, to floor-mounted bolt-on units designed to tip at a specific height for feeding material into larger bins. Tipping heights range from 1000 mm to 3000 mm or more. These units offer a variety of power options, including fully hydraulic, hydraulic chain drive, or electric chain drive.
Our mobile wheelie bin lifts are ideal for lifting 80/120/240 liter wheelie bins, or larger 660/770/1100 liter wheelie bins, into a compactor. These units are equipped with two fixed casters and two swivel brake casters, allowing them to be easily moved from one location to another.
FAQ
1.Are you a factory or trading company?
We are a factory with exporting license.
2.How long is the delivery time for your products?
Normally,15-30 days.
3.How can we guarantee the quality?
Always have pre-production samples before mass production; Always have final inspection before shipment.
4.What services can we provide?
Customized bins are accepted.Someone will answer your questions at any time, 24 hours online.We will provide pre-sales and after-sales service.
5.Do you give any discount ?
I'll surely try my best to help you get those by the best price and good service at the same time.
6.I would like to ask you if it's possible to have my logo on the product.
Absolutely you can, and it's free.
Our garbage compactors are available as both mobile and stationary solutions and can be adapted to many types of waste – such as dry, wet organic, or mixed residual waste. They are ideal for businesses with large amounts of waste – for example in production, retail, or logistics – where efficiency and space utilisation are crucial.
With a press plate, the compactor pushes the waste into a closed container, where it is compressed and therefore takes up significantly less space. This means fewer collections, lower transport costs, and a more orderly workplace.
We are a professional manufacturer of sanitation machinery, providing customers with ex-factory prices and on-demand customization services. You can contact us via WhatsApp or email.
