The Hook Lift Container is a standardized garbage collection container that is used in conjunction with the hook-arm type garbage collection vehicle. Its core feature is that it can achieve rapid connection, lifting and transfer with the mechanical arm of the collection vehicle through the hook/loop structures on both sides or the top of the bin body. It widely replaces traditional manual handling garbage bins and is the core equipment for "mechanized garbage collection" in urban sanitation, park property management and other scenarios.
Looking for a Hook Lift Container that will meet your specific needs?
Hook Lift Containers typically range in size from 10 – 50 Yd., but we can build them to fit your specific requirements. You will find the different standard specifications. And if you don’t find what you’re looking for, we can always customize a Hook Lift Container to fit your specific requirements. So whatever your needs may be, we have a Hook Lift Container that will meet them!
Product Advantage
Traditional trash bins require manual transportation of each one to the collection vehicle, and one vehicle can only clear 10-15 bins in one hour. However, the Hook Lift Container can lift one box at a time through the mechanical arm, and can clear 5-8 boxes in one hour, increasing the efficiency by 3-5 times. It is especially suitable for areas with a large amount of garbage production.
The entire process does not require any cleaning staff to transport or dump the garbage. It only requires operating the mechanical arm of the collection vehicle to complete the "lifting - dumping - returning to position". This avoids the risks of bumps and contamination caused by manual contact with the garbage, fundamentally solving the high-risk problem of traditional garbage collection.
The box is designed as fully enclosed, and during the garbage storage process, there is no odor diffusion or leakage of filtrate (some models have a bottom anti-seepage layer). This can effectively avoid problems such as spillage and attracting insects of traditional trash bins, reducing secondary pollution to the surrounding environment.
Working principle
Lift the container: Drive the Roll off Container to the side of the lifting arm box, extend the hook through the hydraulic arm, and secure the bottom connection mechanism of the container;
Transfer and lift: The hydraulic arm lifts the container as a whole to the top of the truck bed and fixes it. The vehicle is transported to the waste treatment plant (landfill / incineration plant);
Dump and unload: After reaching the destination, the hydraulic arm flips the container and dumps all the garbage into the treatment equipment;
Reposition and reset: After the unloading is completed, the hydraulic arm returns the empty container to the original collection point (or moves it to a new location) to complete one cycle.
Technical Parameters
Product name | Hook bin & Hook lift Bin & Roll on / roll off container |
Material | Mild steel , in China we usually use Q235, which similar to grade 250(AUS), A283(USA). we can also use Q345 which similar to grade |
Size Range | from 10 to 80 yd And OEM is also available. |
Thickness of plates used | 10gauge 8gauge (3mm-4mm) M/S plate for sides and 8 gauge 6gauge(4mm-5mm) M/S for floor. Thicker plates are available to your requirements. |
Other specifications | 1). RHS are used for top rails, and top edge of plate continuous welded to RHS 2). Fully and partly welded inside and outside |
Options | 1) Two openning door 2) Up openning door |
Painting | We will paint each bin you order in your company colour, enhancing your company image with great looking bins.Two times of primer |
Product Customization
RNKJ offers a wide range of Hook Lift Container is what we specialize in. Hook Lift Container come in different sizes, so they can be suitable for any size project for proper waste disposal. Fill the bin with non-recyclable waste (such as concrete, bricks and tiles), and then the truck lifts the bin through a hook, which is the docking point on the back of the bin. The docking point is a sturdy curved metal strip that holds the bin in place when it is hung on the truck. Then, the truck is ready to take the trash can to where it needs to go.
Tailgate Shape
Detailed Images
Our Advantages
Durable and Customizable Design: This refuse collector is designed to meet the specific needs of various construction works, with a customized color option available to suit your preferences.
Heavy-Duty Construction: With a weight of 3000 kg, this hook lift container is built to withstand heavy use and harsh environments, ensuring reliable performance and extended lifespan.
Comprehensive Warranty: We offer a 1-year warranty on the core components, providing peace of mind for our customers and ensuring that any issues are addressed promptly.
Compliance with Industry Standards: Our product meets all necessary regulations and standards, with a provided machinery test report and video outgoing-inspection available for review.
Tailored to Your Needs: As a user, you can expect a product that is designed to meet the specific requirements of construction works, with a production capacity that can be tailored to your needs.
Our hook bins has hundreds of styles. We can design & produce any hook bin according to customer's requirement. Our Tech. Dpt. can also provide the temporary design drawings for your confirmation. OEM is also available.
Packaging & Delivery
Packing Details: No packing , loaded in shipping container.（Usually we stack your bins with foam to protect your painting , also we can provide some paint with the bins for fixing when you got the bins）
Delivery Details: Shipped in 10 days after payment. (Usually we need 30% as deposit, and balanced will be paid after sending you the scanned copy of documents like B/L, Invoice packing list and so on)
FAQ
Are you a manufacturer or Trader?
We are a professional manufacture, we have our own R&D team and sales team, we provide one-stop service.
What is your payment term?
We accept T/T, L/C at sight, Western Union, Paypal etc.
How long is the validity of quotation?
Generally, our price is valid within one month from the date of quotation. The price will be adjusted appropriately according to the price fluctuation of raw materials and changes in market.
What is your delivery time?
Usually, we make merchandise inventory. If we have the products in stock, the delivery time is 5-10 days after receiving the deposit. If we don't have the products in stock, we will arrange the production right now, the delivery time will be 10-30 days. It depends on the order quantity.
Do you provide OEM/ODM Service?
Yes, with necessary information, we provide custom-make service to meet different needs of global clients with different budgets.
How can we ensure quality?
The final inspection is always carried out before shipment.
How to install the equipment after purchasing?
We will provide a professional installation video to illustrate, as well as a manual.
Do you offer a guarantee?
Yes, we guarantee our product for one year. After-sales service support and technical support are both available.
What is your MOQ?
1 set.
We are a professional manufacturer of sanitation machinery, providing customers with ex-factory prices and on-demand customization services. You can contact us via WhatsApp or email.
