Hook Lift Container Bin are specialized containers designed for efficient waste collection and transportation, typically used in construction, demolition, and industrial applications
They are lifted and lowered using a hook lift system, which allows for easy loading and unloading without the need for a crane.
Looking for a Hook Lift Container Bin that checks all your boxes?
Our Hook Lift Container Bin has hundreds of styles.We can design & produce any Hook Lift Container Bin according to customer's requirement. Our Tech. Dpt. can also provide the temporary design drawings for your confirmation. OEM is also available.
We produce various sizes of Hook Lift Container Bin, with the maximum capacity reaching up to 40 cubic meters. The design of the hook-type container is aimed at adapting to your transportation method. The height and spacing of the hooks can meet your requirements, and it can be in the form of hook-type, trailer-type, roll-on/roll-off type, or a combination of both, depending on your specific needs. Please inform our sales team of your company's requirements, and we will design, manufacture, and provide a Hookift model container for your application based on your specific needs.
Product Advantage
High Transfer Efficiency: The hook-arm truck independently handles loading and unloading, eliminating the need for auxiliary equipment such as cranes. Each operation takes only 5-10 minutes, significantly reducing site occupancy time.
High Adaptability: The hook-arm truck can be adapted to various sizes, enabling operation in complex locations such as construction sites, residential communities, and industrial parks. It is particularly well-suited for areas with limited space or limited access for vehicles.
Low Overall Cost: One hook-arm truck can be used with multiple containers for recycling, reducing equipment purchases. Containers can also be stored on-site temporarily, reducing labor costs.
Provide transportation solutions
We provide customized solutionsengineers will make 3D modelingdrawings according to customerrequirements, CAD drawings to solvepractical problems for more customers.
Our products support 100% customization, including size, color, plate thickness, hook height, etc.We believe that our factory can meet your special needs.
Working principle
Vehicle Positioning and Connection: The hooklift truck drives to the container and adjusts its position so that the hydraulic hook arm aligns with the hook at the bottom of the container, completing the mechanical connection.
Hydraulic Lifting and Loading: Activating the hydraulic system causes the hook arm to lift and tilt the entire container, automatically unloading materials (such as garbage and waste); or, in reverse, to lift an empty container from the ground and secure it in the truck bed.
Transfer and Reset: The hooklift truck transfers a filled container to a disposal site (such as a landfill or recycling station). After unloading, the empty container is returned to its original location or transported to the next required work site.
Applications
Construction sites: clearing gravel, wood, abandoned building materials, etc., supporting temporary stacking and regular emptying.
Municipal engineering: handling road maintenance waste, greening waste or ruins after disasters.
Commercial places: centralized treatment of waste from shopping mall decoration and garbage after large-scale events.
Industrial field: factory scrap metal, plastic scraps or hazardous waste (custom sealed boxes are required).
Technical Parameters
Product name | Hook bin & Hook lift Bin & Roll on / roll off container & Roll Off Container Dumpster |
Material | Mild steel , in China we usually use Q235, which similar to grade 250(AUS), A283(USA). we can also use Q345 which similar to grade |
Size Range | from 10 to 80 yd And OEM is also available. |
Thickness of plates used | 10gauge 8gauge (3mm-4mm) M/S plate for sides and 8 gauge 6gauge(4mm-5mm) M/S for floor. Thicker plates are available to your requirements. |
Other specifications | 1). RHS are used for top rails, and top edge of plate continuous welded to RHS 2). Fully and partly welded inside and outside |
Options | 1) Two openning door 2) Up openning door |
Painting | We will paint each bin you order in your company colour, enhancing your company image with great looking bins.Two times of primer |
Detailed Images
Hook
Our hook can be customized,strong and durable.We take the highest weight-to -lift ratio in the industry. we use high tensile steel for reducing bins weight , which means more payload,longevity of truck life time.
Doors Hinges
Our doors hinges are greasable and capable of holding a big weight as well as mounting and adjustment are very easy.
Wheels
Our wheels are heavy duty ,have great flexibility in using ,can be a good optional to our customers.
Door lock
Door locking mechanism with high tensile safety chain and catch,this operates a heavy-duty secure locking mechanism .We also can customize the door locking mechanism to suit various transportation methods and requirements.
Our Advantages
Durable & Customizable Design
Engineered to align with the unique demands of diverse construction projects, this refuse collector offers tailored solutions—including customizable color options—to match your operational branding or site-specific preferences, ensuring both functionality and visual coherence.
Heavy-Duty Construction for Long-Term Reliability
Boasting a robust 3000 kg build, this hook lift container is engineered to endure heavy usage and harsh environmental conditions, delivering consistent performance and an extended service life for maximum operational value.
Comprehensive Warranty for Peace of Mind
We stand behind our product with a 1-year warranty covering core components, providing customers with reassurance and prompt resolution for any potential issues, reinforcing our commitment to quality and customer satisfaction.
Strict Compliance with Industry Standards
Our hook lift container adheres to all relevant regulations and industry benchmarks, supported by a detailed machinery test report and video documentation of outgoing inspections, ensuring full transparency and compliance for seamless integration into your workflow.
Tailored Solutions for Your Unique Needs
Designed with construction-specific requirements in mind, the product offers flexible production capacity adjustments to accommodate varying project scales, ensuring it aligns perfectly with your operational demands—whether for small-scale renovations or large infrastructure developments.
FAQ
1.Q: Are you trading company or factory ?
A: We are a professional factory with exporting license.
2.Q: Can you design for us?
A:Yes, we can customize design and produce the bins as per customer’s requirement.
3. Q: What size hook lift bin are available?
A: The range of available sizes to choose from are: 10m3 to 40m3 General.
4.Q: What’s lead time ?
A: Most of orders can be finished within 15-20 working days.
5. Q: What does your factory do regarding quality control?
A: 1)Professional engineer design drawing before production
we have excellent process machine
2) Skilled workers are used in crucial production process
3) Quality Control Department will check all process like raw material, cutting sizes, parts welding, fully welding and the
finished products to make sure they can meet the quality.
We are a professional manufacturer of sanitation machinery, providing customers with ex-factory prices and on-demand customization services. You can contact us via WhatsApp or email.
