The floor scrubber is a mechanized equipment specifically designed for large-scale floor cleaning. Its core feature is "driver-operated operation" - the operator can sit in the driving position of the equipment to control its operation, without the need for manual pushing.
Its core functions integrate three modules: floor scrubbing, immediate water absorption, and wastewater recovery. It can complete the entire process of stain removal, water absorption, and wastewater collection simultaneously in a single operation, without the need for additional step-by-step operations.
Floor scrubber is mainly suitable for large-scale and high-frequency cleaning scenarios, such as airport terminals, large warehouses, chain supermarkets, industrial workshops, exhibition centers, etc.
Floor scrubber is particularly suitable for places that require quick restoration of floor use and have high standards for cleaning standardization. Floor scrubber can effectively replace the inefficient operation mode of traditional manual cleaning and hand-push floor scrubbers.
Product Advantage
1. Cleaning efficiency: Higher than manual and hand-push types, significantly reducing the operation time.
Coverage area: The conventional driving-type floor scrubber can clean an area of 0-8100 square meters per hour, which is 2-5 times that of the hand-push type and 10-25 times that of manual cleaning.
Continuous operation: Equipped with large-capacity dual water tanks, it eliminates the need for frequent shutdowns for water replenishment or sewage discharge. A full tank can enable continuous cleaning for 2-4 hours, avoiding the time waste of repeatedly lifting water and pouring sewage by manual workers.
2. Operating experience: Effortless and low consumption, reducing the burden on operators.
Driver's seat design reduces fatigue: Compared to the hand-push type that requires continuous force to push, the driving type is controlled by the steering wheel for direction, and the operator only needs to sit and operate, which can significantly reduce the strain on the waist and arms, suitable for high-intensity scenarios of 8-hour continuous cleaning;
Simple operation: No professional skills required, new operators can operate independently after 15-30 minutes of training, reducing personnel training costs.
3. Function integration: Completes multiple processes in one step, avoiding secondary pollution.
Full-process synchronization: Breaks through the traditional manual "sweeping - mopping - drying" step-by-step mode, scrubbing through the high-speed rotation of the brush disc to remove stains, while the suction扒 simultaneously absorbs and dries the ground moisture， the sewage is directly recycled to an independent water tank， achieving "cleaning and drying simultaneously"， avoiding the risk of slipping caused by residual moisture on the ground， and eliminating the need for subsequent manual drying；
Reducing secondary dust： During the cleaning process， the sewage and dust are collected in a closed manner throughout the process， unlike manual sweeping， which generates dust， especially suitable for scenarios with high air cleanliness requirements such as hospitals and electronic factories.
4. Scene adaptation： Suitable for complex large-scale scenarios， with strong stability.
Adaptable to various floors： Can be adapted to different materials such as ceramic tiles， cement floors， epoxy floors， and stone floors through changing the brush disc， balancing "cleaning power" and "floor protection"；
Adaptability to complex environments： Some industrial-grade models are equipped with dual braking systems， anti-collision strips， and anti-slip tires， which can operate stably in scenarios with slopes and obstacles， avoiding equipment collisions or slips.
5. Cost and environmental protection： Long-term cost reduction， in line with green standards.
Cost savings in labor： One driving-type floor scrubber can replace 8-12 cleaners；
Water and energy conservation： Through precise control of water usage， and some models supporting sewage filtration and recycling； the motor adopts efficient energy-saving design， with an hourly power consumption of only 2-5 degrees， lower than traditional high-pressure cleaning equipment；
Low noise and environmental protection： Commercial models have low operating noise， which can operate during non-closed periods such as business hours in shopping malls and hospital visits， without interfering with normal operations.
Technical Parameters
Product Parameters | |||
Cleaning width | 900mm | Suction motor | 24V/600W |
Suction width | 1250mm | Drive motor | 24V/1200W |
Brush plate size | 450mm*2 | Washing water pump | 24V/120W |
Working efficiency | 0-8100m²/h | Vehicle weight | 370KG |
Water tank capacity | 150L | Vehicle dimensions | 1660*1250*1380mm |
Sewage tank capacity | 160L | Packaging dimensions | 1765*1020*1610mm |
Working time | 3-4H | Minimum turning radius | 270mm |
Travel speed | High speed 0-7km/h/Low speed 0-3km/h | Tyre model | Front 250*70 rear 350*80polyurethane solid tires |
Battery capacity | 24V/200Ah | Braking method | Mechanical brake +electronic brake + anti-slip |
Brush plate motor | 24V/550W*2 | Battery type | Maintenance-free lead-acid/lithium battery |
Features
Due to its efficient and flexible cleaning capabilities, the Floor Scrubber is widely used in various large-area, high-frequency cleaning scenarios, especially in places where cleaning efficiency and standardized operations need to be improved. The ride-on design allows operators to sit and drive the equipment. Compared with push-type floor scrubbers, it can quickly cover large areas of the ground, especially suitable for large places such as airports, warehouses, and supermarkets. Floor Scrubber integrates floor scrubbing, water absorption, and sewage recovery, and completes multiple processes in one operation, avoiding the step-by-step operation of "sweeping - mopping - draining" in traditional manual cleaning, reducing repetitive labor.
Product Overview
Applicable scenarios
Optional Charger And Plug
For any other chargers and plugs, please contact us.
Product Details
Product Function
Factory Display
Packaging and Delivery
FAQ
Question: Are you a factory or trading company?
Answer: We are a factory with our own export authority, which have many employees with strong R&D ability
Question: Some customers have some new item or part but can find in the web-site,can you product it?
Answer: we need images or artworks, samples you provide. lf you have 3D artwork will help us to checkfaster, Evaluating and considering product in mass production is workable according our equipment, Wewill give you a detail quotation.
Question: How do u ensure your product quality?
Answer: We have a system quality control procedure, from incoming material, part, semi-product andfinal product 100% check. Material, semi-product, product function
Question: How do u do with the after-sales service?
Answer: For our design/production/package problems, Ruining will take full responsibility. For shipmentproblems, we have full reports to help claims with shipping company.
We are a professional manufacturer of sanitation machinery, providing customers with ex-factory prices and on-demand customization services. You can contact us via WhatsApp or email.
